TE Connectivity 282089-1 AMP SUPERSEAL 1.5 Plug, 5 Way Connector Housing (bag of 10)
TE Connectivity 282089-1 AMP SUPERSEAL 1.5 Plug, 5 Way, 1 Row Connector Housing (bag of 10)
TE Connectivity 282089-1 AMP SUPERSEAL 1.5 Plug, 5 Way, 1 Row Connector Housing (bag of 10)
TE Connectivity SUPERSEAL Series 1.5 Automotive Connectors
SUPERSEAL series 1.5 automotive connectors offered in plug housings for receptacle contacts, and cap housings for tab contact variants. These connectors are made from black 6.6 glass filled polyamide with a pre-assembled secondary lock. The automotive connector plug housings have silicon rubber seals, and the cap housings can also be panel mounted. Durable hard wearing automotive connectors, suitable for many solutions, including truck, bus, agriculture, and off-road vehicles.
Features and Benefits
Waterproof exceeding IP67
Proven sealing reliability
Designed for under-hood environments
Suitable for powertrain, security, and body & chassis systems
Wire seals constructed of silicon rubber
Dielectric withstand voltage 1500 Vrms
Temperature range -40 to +125°C
| Rating | 60 Vdc 14A max. |
| Crimp material: | |
| - tab | tin plated brass |
| - receptacle | tin plated phosphor bronze |
| Contact resistance | 30m Ω max. |
| Wire size range: | 0.35 - 0.5 mm2 |
| 1.0 - 1.5 mm2 | |
| Insulation Material | polyamide 6.6 glass filled |
| Temperature rating | -40° to +125°C |
| Attribute | Value |
|---|---|
| Number of Contacts | 5 |
| Number of Rows | 1 |
| Pitch | 6mm |
| Gender | Female |
| Series | AMP Superseal 1.5 |
| For Use With | Centerline Wire-to-Wire Connector |
| Body Orientation | Straight |
| Length | 32.2mm |
| Housing Material | Nylon |
| CAD Drawing | 3D CAD Model |
| Manufacturer | IONNIC |
|---|
-
