Hella 2LT980620801 2NM NaviLED Deck Mount Port and Starboard Pair (Black Shroud - Coloured Lens)

Hella 2LT980620801 2NM NaviLED Deck Mount Port and Starboard Pair (Black Shroud - Coloured Lens)

Hella 2LT980620801 2NM NaviLED Deck Mount Port and Starboard Pair (Black Shroud - Coloured Lens)

Compact deck mount LED navigation lamps.
Attractive, power saving and ultra reliable.

Ultra low current draw
NaviLED lamps use less than 10% of the power required to run a bulb navigation lamp of the same visible distance. Port and Starboard lamps consume less than 2 watts combined !

No bulbs, No maintenance. Ultra long service life
Hella marine LED technology has no filaments to break making NaviLED lamps extremely shock and vibration proof for reliability and safety in demanding conditions.

MultivoltTM 8-28V DC
Advanced electronics ensure reliable illumination and lamp protection even under severe voltage fluctuations and low battery voltages.

Safe and highly visible
Hella marine optics deliver 100% correct light output and enhanced visibility compared to bulb navigation lamps.

Fully sealed for life. IP 67 Certified
Each NaviLED lamp is a completely sealed unit. High impact housings ensure durability from waves and impact.

Specifications:

Material Description: UV resistant, enhanced impact resistant acrylic lens High impact shroud
Minimum Visible Distance: 2 Nautical Miles (Yachts and Powerboats)
Cable: Pre-wired with 500mm of twin core marine cable
Operating Voltage: Multivolt 8-28V DC
Voltage Protection: Spike protected to +500 volts, Reverse polarity protected to -700 volts
Power Consumption: Port and Starboard less than 2W combined
Degree of Protection: IP 67 - Completely Sealed
Weight: 75g (including cable)
Approvals: IMO Col Reg 72, RINA, USCG, ABYC A-16, Maritime NZ

Position Light - NaviLED M - LED - 12/24V - Bolted/mounting - COLREG 72/ABYC/Maritime NZ/ECE/USCG - Lens Colour: Green/Red - Cable: 500mm - outer - Quantity: 1

Features

• Length: 50mm - Width: 39mm - Height: 39mm - Lamp Type: LED
• Light functions: 1 - with marker lamp (LED)
• Registration Type: COLREG 72/ABYC/Maritime NZ/ECE/USCG - Prot.type (IP Code): IP67
• Housing Colour: Black - Lens Colour: Green/Red
• Mounting Type: Bolted/mounting

Specifications

• Part number: 2LT980620801
• Hella number: 2LT 980 620-801
• Barcode (EAN): 9002920143622
• Brand: Hella
• Mounting Type: Bolted / mounting
• Light Design: LED
• Lamp Type: LED
• Voltage: 12 / 24 V
• Fitting Position: outer
• Height: 39 mm
• Width: 39 mm
• Length: 50 mm
• Light Function: with marker lamp (LED)
• Number of light functions: 1
• Protection Type per ISO 20653: IP67
• Registration Type: ABYC / COLREG 72 / ECE approved / Maritime NZ / USCG
• Cable Length: 500 mm
• Housing Colour: black
• Lens Colour: green / red
• Power Consumption: 2 W
• Product line: NaviLED M

Assy./disassy. by qualified personnel required!
